Odpływ liniowy ścienny Balneo W-Drain NEXT 2w1 60 cm złoty dwustronny
Odpływ liniowy ścienny Balneo W-Drain NEXT 2w1 60 cm złoty dwustronny
Technical data
Brand
Balneo
EAN
5905591096218
SKU
A0301030102-1
Producer code
5905591096218
Series
W-DRAIN NEXT
Drain type
Linear
Length
60 cm
Throughput
55 l/min.
Minimum installation depth
66 mm
Drain diameter
40 mm
Width of drain cover
4,4 cm
Surrounding flange
2 cm
Possibility to paste a plate
Yes
Swivel siphon
No
Finishing
Coating PVD
Siphon included
Yes
Contents of the kit
Casing, double-sided panel, siphon trap, sediment trap, sealing mat, adjustable feet, reduction 40/50, hook for removing panel
Material
AISI 304 stainless steel
Colour
Gold
Weight
2,8 kg
Dimensions
60 x 4,4 x 6,6 cm
Size
60 cm
W-DRAIN NEXT: STYLISH DRAINS
wall-mounted linear
Series W-Drain Next is a modern solution for bathrooms that combines functionality, durability, and elegance. Made from high-quality AISI 304 stainless steel, these drains stand out for their corrosion resistance and wide range of colors. The reversible panel lets you choose between a smooth surface or tile insertion, providing full freedom in design. The drain’s construction eliminates the need for spacer inserts, ensuring easy installation and excellent stability.
W-DRAIN NEXT GOLD - LUXURY IN A GOLD FINISH
Model W-Drain Next Gold is designed for those who appreciate luxurious finishes and high functionality. The drain features an elegant PVD gold coating that is durable, damage-resistant, and perfectly suited to glamour, classic, and modern interiors. The reversible panel allows for tile insertion or use of the smooth surface, making this model extremely versatile.
With a flow rate of 55 l/min and a basket-type strainer, the drain provides user convenience and easy maintenance. Adjustable feet and precise panel fitting make installation quick and simple. W-Drain Next Gold is an investment in aesthetics and durability for years to come.
GOLDEN ELEGANCE FOR EXCEPTIONAL INTERIORS
The W-Drain Next Gold drain is designed with the most demanding users in mind. The PVD coating not only gives the product a luxurious appearance but also enhances its resistance to corrosion and chemicals. It’s the ideal solution for those seeking refined style and long-lasting durability.
SIMPLE INSTALLATION AND USE
Adjustable feet, no need for spacer inserts, and a basket-type strainer make installation and maintenance quick and convenient. The drain’s construction ensures stability and precise fit, while the wet siphon guarantees efficient water drainage.
DURABILITY FOR YEARS
High-quality AISI 304 stainless steel and a carefully engineered drain design ensure reliability for many years. The product comes with a 10-year warranty on the body and a 2-year warranty on the PVD coating, reflecting its exceptional quality.
TECHNICAL DATA
BRAND: Balneo
SERIES: W-DRAIN NEXT
COLOR: Gold
SIZE: 60 cm
DIMENSIONS: 60 × 4.4 × 6.6 cm
WEIGHT: 2.8 kg
MATERIAL: AISI 304 stainless steel
FINISH: PVD
DRAIN TYPE: Linear
FLOW RATE: 55 l/min
OUTLET DIAMETER: 40 mm
DRAIN COVER WIDTH: 4.4 cm
PERIMETER FLANGE: 2 cm
ROTATING SIPHON: No
TILE INSERT OPTION: Yes
MINIMUM INSTALLATION DEPTH: 66 mm
INCLUDES: body, reversible panel, siphon, strainer, sealing mat, adjustable feet, 40/50 reducer, panel removal tool
EAN: 5905591096218
SKU: A0301030102-1
WARRANTY: 10 years on body, 2 years on coating
YOUR SAFETY
is important to us
10-YEAR WARRANTY
TECHNICAL SUPPORT
PZH CERTIFICATE
90-DAY RETURNS
FAQ
What is the drain made of?
Drain made of stainless steel.
What is the water flow rate of the drain?
The water flow rate is 55 l/min.
Do the drains have a reversible panel?
Yes, the drain has a reversible panel in which you can mount a tile.
What is the width of the panel?
The panel width is 4.4 cm.
What is the minimum installation depth for this drain?
66 mm
Are the drain’s legs adjustable?
Yes, the drain’s legs are adjustable.
Is it possible to install the drain in vinyl panels?
This drain is not dedicated for that type of installation.
Does the drain have a dry siphon?
No. The drain is equipped with a wet siphon.
Can the siphon be replaced with a dry one?
No.
Does the drain come with a complete installation kit?
Yes. Our drains include everything needed for installation.
What is the metal thickness?
1 mm thick.
How do you remove the panel from the linear drain?
A key is included, which allows you to lift the panel from the linear drain.
Can you purchase a panel separately for the linear drain?
Yes, you can buy the panel separately.
Is the panel fixed in the linear drain?
Yes, thanks to the included spacers, the panel stays firmly in the drain.
