Odpływ liniowy ścienny Balneo W-Drain NEXT 2w1 90 cm złoty dwustronny
Odpływ liniowy ścienny Balneo W-Drain NEXT 2w1 90 cm złoty dwustronny
Technical data
Brand
Balneo
EAN
5905591096249
SKU
A0301030102-4
Producer code
5905591096249
Series
W-DRAIN NEXT
Drain type
Linear
Length
90 cm
Throughput
55 l/min.
Minimum installation depth
66 mm
Drain diameter
40 mm
Width of drain cover
4,4 cm
Surrounding flange
2 cm
Possibility to paste a plate
Yes
Swivel siphon
No
Finishing
Coating PVD
Siphon included
Yes
Contents of the kit
Casing, double-sided panel, siphon trap, sediment trap, sealing mat, adjustable feet, reduction 40/50, hook for removing panel
Material
AISI 304 stainless steel
Colour
Gold
Weight
3,4 kg
Dimensions
90 x 4,4 x 6,6 cm
Size
90 cm
W-DRAIN NEXT: STYLISH DRAINS
linear wall drains
The W-Drain Next series is a modern solution for bathrooms that combines functionality, durability, and elegance. Made from high-quality AISI 304 stainless steel, these drains are corrosion-resistant and available in a wide range of colors. The reversible panel allows you to choose between a smooth surface or tile insertion, giving you complete design freedom. The drain’s construction eliminates the need for spacer inserts, ensuring easy installation and excellent stability.
W-DRAIN NEXT GOLD – LUXURY IN A GOLD FINISH
The W-Drain Next Gold model is designed for those who value a luxurious finish and high functionality. The drain features an elegant gold PVD coating that is durable, damage-resistant, and perfectly suited to glamorous, classic, or modern interiors. The reversible panel allows tile insertion or use of the smooth surface, making this model exceptionally versatile.
With a flow capacity of 55 l/min and a basket strainer, the drain offers user convenience and easy maintenance. Adjustable feet and precise panel fitting make installation quick and simple. W-Drain Next Gold is an investment in aesthetics and long-term durability.
GOLDEN ELEGANCE FOR EXCEPTIONAL INTERIORS
The W-Drain Next Gold drain has been designed for the most demanding users. The PVD coating not only gives the product a luxurious appearance but also enhances its resistance to corrosion and chemical agents. It’s the ideal solution for those seeking refined style and long-lasting durability.
EASY INSTALLATION AND USE
Adjustable feet, no need for spacer inserts, and the basket strainer make installation and maintenance quick and convenient. The drain’s design ensures stability and precise fitting, while the wet trap provides effective water drainage.
DURABILITY FOR YEARS
High-quality AISI 304 stainless steel and a thoughtfully designed drain construction ensure reliability for many years. The product includes a 10-year warranty on the body and a 2-year warranty on the PVD coating, reflecting its exceptional quality.
TECHNICAL DATA
BRAND: Balneo
SERIES: W-DRAIN NEXT
COLOR: Gold
SIZE: 90 cm
DIMENSIONS: 90 × 4.4 × 6.6 cm
WEIGHT: 3.4 kg
MATERIAL: AISI 304 stainless steel
FINISH: PVD
DRAIN TYPE: Linear
CAPACITY: 55 l/min
DRAIN DIAMETER: 40 mm
DRAIN COVER WIDTH: 4.4 cm
SURROUNDING FLANGE: 2 cm
ROTATING TRAP: No
TILE INSERTABLE: Yes
MINIMUM INSTALLATION DEPTH: 66 mm
IN THE SET: body, reversible panel, trap, strainer,
sealing mat, adjustable feet, 40/50 reducer, panel-removal hook
EAN: 5905591096249
SKU: A0301030102-4
WARRANTY: 10 years on the body, 2 years on the coating
YOUR SAFETY
is important to us
10-YEAR WARRANTY
TECHNICAL SUPPORT
PZH CERTIFICATE
90-DAY RETURNS
FAQ
What is the drain made of?
The drain is made of stainless steel.
What is the water flow capacity of the drain?
The water flow capacity is 55 l/min.
Do the drains have a reversible panel?
Yes, the drain has a reversible panel that allows tile installation.
What is the width of the panel?
The panel width is 4.4 cm.
What is the minimum installation depth for this drain?
66 mm
Are the drain feet adjustable?
Yes, the drain feet are adjustable.
Is it possible to install the drain in vinyl panels?
This drain is not intended for that type of installation.
Does the drain have a dry trap?
No. The drain is equipped with a wet trap.
Can the trap be replaced with a dry one?
No.
Does the drain include a complete installation kit?
Yes. Our drains include everything needed for installation.
What is the metal thickness?
The thickness is 1 mm.
How to remove the panel from the linear drain?
The set includes a key that allows you to lift the panel from the linear drain.
Can you purchase the panel for the linear drain separately?
Yes, the panel can be purchased separately.
Is the panel fixed in the linear drain?
Yes, thanks to the included spacers, the panel stays firmly in the drain.
